Microchip offers numerous development boards which have a built-in RJ-12 jack for ICSP, allowing for the direct connection of the ICD3.Įxplorer 16 Development Board with 100-pin PIMĪs well as many other Microchip development boards.īoth offer plug-in modules (PIM) to easily change to target microcontroller and either Pictail or Pictail Plus bus connectors to plug-in additional development modules or allow easy access to all the available pins of the microcontroller.Īn often underused resource, is the freely available schematics and board designs available for most of Microchip's development boards.
Please read the attached user guide, as it contains valuable information. The pinouts above should give you the required information for constructing your own custom cables.
#Microchip icd3 driver windows 8 install#
If you were to install an RJ-12 on your design, keeping in mind the cable is a straight through configuration, the connections would be reversed looking into the RJ-12 jack from left to right: Looking into the RJ-12 jack of the ICD3 from left to right the pinouts are: If you build your own cables, make sure you buy RJ-12s and matching six conductor cable, with the cable constructed straight through. Microchip mistakenly refers to the connector as an RJ-11, which is a six position, four conductor connector (6P4C), when in fact it is an RJ-12, which is a six position, six conductor connector (6P6C). I've attached both the ICD3 User Guide and Quick Reference Sheet, I've also posted the image of the ICD3 pinouts below: Or any other manor of adapter cable variation you can imagine: Or you can make your own programming cable with male pin headers which can plug directly into a breadboard: Or simply incorporate an RJ12 Jack or any other variety of interface into your design to directly accept the a cable from the ICD3: You can continue to use this cable with your circuits or designs when combined with an RJ12 Jack breakout board, like the following: The ICD3 typically comes with a standard RJ12 to RJ12, straight through six conductor cable which is designed to plug directly into most of Microchip's development boards: You may need the poor little test module in the future.Īll you need it to properly interface the ICD3 to your circuit or design is the cable and NOT the test module. It has nothing to do with the actual programming/debugging interface to your circuit or design. The gadget you are referring to is the ICD3 test module for troubleshooting the ICD3 if technical issues should arise, it essential tests a loop back condition. The programming header would be connected to the PIC same voltage source of 5V or it must have a unique voltage source of 3,3V? I`m using PIC18F4520, and its input voltage must be of 5V. In the pic24.jpg that you had attached, the PIC input voltage source is of 3.3V similarly for the programming header, since in the photo the PIC you showed was PIC24F
Pin1 to MCLR and place between MCLR and Vdd of the PIC a 10k resistor as: a pull-up resistor so that the line may be strobed low to reset the deviceĪs a summary the PIC should have its own power source of 5V, and must have its 20Mhz external crystal with its 22pF electrolytic caps branched in, the output of the MPLAB ICD3 goes to the photo1 and photo3 goes to the pic with connections as stated above. This is what I will do, please state wether true or false:ġ) connect the MPLAB ICD3 incircuit debugger with the USB interface to the laptopģ) I will attach wires to the photo1 by soldering iron, by taking into consideration each pinout according to its datasheetĥ) after the photo1 has soldered wires as it shows on photo3 i will put the PIC into a breadboardĦ) connect both VDD to +5V and both Vss to GNDħ) place the XTAL external oscillator of 20Mhz at pins 13 and 14 and place a 22pF from each terminal to GNDĨ) concerning photo3 that reveals the MPLAB ICD3 RJ-11 Jack pinout, I will connect the pins as follows: I found out that the gadget has an interface board with the datasheet concerning.
